|Product:||Biological Safety Cabinet||External Size:||L;700*W:650*H:1230 Mm|
|Consumption:||700 W||Internal Size:||L:600*W:500*H:540 Mm|
|Work Zone Material:||304 Stainless Steel||Power Supply:||AC220V±10% ,50/60 Hz;110V±10%，60Hz|
biological safety hood,
biohazard safety cabinet
70% air Re-circulation Desktop Class II A2 Biological Safety Cabinet
2.1 Three protection: operator, sample and environment.
2.2 Airflow system: 0 % air recirculation, 100% air exhaust
2.3 B2 Biological Safety Cabinet has higher class of safety protection compared with type A2,
2.4 It may be used for work with volatile toxic chemicals and radionuclides as required as adjuncts to microbiological studies
1. Motorized Front Window.
2. Time Reserve Function.
3. HEPA Filter life and UV Life indicator.
4. Automatic air speed adjustable with filter block.
5. Work area surrounded by negative pressure, it can ensure maximum safety in work area.
6. Audio and visual alarm (Filter replacement, Window over height, abnormal Air flow velocity etc).
7. Most accessories are standard. No need to pay more, save your money.
8. Remote Control. All functions can be realized with it, making the operation much easier and more convenient.
9. Foot Switch. Adjust front window height by foot during experiment, to avoid airflow turbulence caused by arm movement.
10. Interlock Function: UV lamp and front window; UV lamp and blower, fluorescent lamp; Blower and front window.
4. Technical Data
|External Size(W*D*H)||700*650*1230 mm|
|Internal Size(W*D*H)||600*500*540 mm|
|Tested Opening||Safety height: 200mm(8")|
|Max Opening||370 mm(15’’)|
|Inflow Velocity||0.53±0.025 m/s|
|Down Flow Velocity||0.33±0.025 m/s|
|HEPA Filter||Two, 99.999% efficient at 0.3μm. Filter life indicator.|
|Front Window||Motorized. Two-layer laminated toughened glass ≥ 5mm. Anti UV.|
|Noise||EN12469 ≤ 58 dB / NSF49 ≤ 61 dB|
UV timer, UV life indicator, emission of 253.7 nanometers
for most efficient decontamination.
|Socket||Two, total load of two sockets: 500W|
LCD display: exhaust filter and downflow filter pressure, filter and
UV lamp working time, inflow and downflow velocity,filter life,
humidity and temperature, system working time etc.
|Airflow System||70% air recirculation, 30% air exhaust|
|Visual and Audio alarm||Filter replacement, window over height, abnormal air flow velocity.|
|Material||Work Zone: 304 stainless steel|
|Main Body: Cold-rolled steel with anti-bacteria powder coating.|
|Work Surface Height||750mm with optional base stand|
|Power Supply||AC220V±10%, 50/60Hz; 110V±10%,60Hz|
|Standard Accessory||Fluorescent lamp, UV lamp*2, Remote control, Waterproof sockets*2|
|Optional Accessory||Base stand, Universal caster with brake and leveling feet.|
|Gross Weight without Base Stand||Wooden: 164kg Carton:121kg|
|Gross weight with Base Stand||Wooden:196kg|
|Package Size without Base Stand (W*D*H)||Wooden:860*800*1450mm Carton:820*760*1430mm|
|Package Size with Base Stand (W*D*H)||
