Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture

Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture
Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture

Large Image :  Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture

Product Details:
Place of Origin: Guangzhou, China
Brand Name: Mytop
Model Number: MT-FST-3000
Payment & Shipping Terms:
Minimum Order Quantity: I Meter
Price: Negotiable
Packaging Details: Carton box or plywood wood packing
Delivery Time: 7 to 15 working days after we
Payment Terms: T/T, L/C, Western Union
Supply Ability: Over 20,000 Meter Per Month
Contact Now
Detailed Product Description
Meterial: 1.2 Mm Cold Roll Steel Sheet Finishing: High Temperature Epoxy Power Coating
Worktop: 19 Mm White Color Epoxy Resin Worktop Supporting: 60*40*1.5 Mm C Frame
Worktop Loading Capacity: Over 300 Kg Per Meter Reagent Rack Column: Aluminum Alloy
Reagent Rack Layer: 10 Mm Tempering Glass Reagent Rack Loading Capacity: Over 50 Kg Per Layer
Highlight:

modular laboratory furniture

,

steel laboratory furniture

1. Product:



Customized Modular Metal Laboratory Furniture With Starch Resistance Worktop





2. Technical Data



A. Worktop: The worktop is based on the requirement of customers such as phenolic resin board, epoxy resin board or ceramic board. The edge of worktop will be treated specially to ensure its safety for human body.
B. Structure: Steel structure, full cabinet design, the material for cabinet is 1.0mm BAOGANG cold rolled sheet. The processing procedures includes cutting, grooving, bending, shaping, assembling and polishing. The products are produced by precise CNC machine. All the welding points have been polished specially which will not hurt the hand. The inside cabinet is with front and back upright columns and reinforcing ribs to increase the bearing capacity and impact resistance capacity.
C. Cabinet: The cabinet is made of high quality cold rolled sheet with different thickness as per its different loading weight. The surface is treated by acid washing, phosphorization before coating by epoxy resin powder. The cabinets can be opened with all blank space without middle support. The inside cabinet is equipped with adjustable setting for mobile layer.
D. C-Frame: It's made of 60x40x1.5mm steel pipe coated with epoxy resin powder.
E. Surface panel for door and drawer: The door is with double layer made of 1.0 BAOGANG cold rolled sheet. We can fill the sound insulation material into the inside space between two layers if it's required by customer. The drawer is shaped once made of bending cold rolled sheets. It's with excellent bearing capacity for the support of drawer. The sealed panel after bending connects with the outside drawer surface by self-drilling screws. It can prevent the crashing when closing the drawer and noise caused by abrasing the coated layer.
F. Bottom panel for cabinet body: The bottom panel is formed once with reinforcing ribs to increase its bearing capacity and prevent the deforming of steel layers.
G. Handle: Stainless steel U-type handle or long handle shaped once made of steel.
H. Movable back panel: Movable and free dissembling structure which is convenient for checking water, electricity and gas pipe etc.
I. Movable layer: It's with reinforcing rib inside to increase its bearing capacity to avoid deforming. It can be dissembled freely and the height can be adjusted.
J. Hinge: Using durable DTC 90 degree or 304 stainless steel hinge which can be used for long time.
K. Drawer sliding rail: Using 3-joints bearing drawer rail with noise reduction, it can ensure the full opening for the drawer with good bearing capacity and without deforming.
L. Shelf: The shelf is made of steel frame and steel hanging pieces. The layer is made of toughened glass which is suitable to put all kinds of chemicals on it.


3. More WAorktop Option

 Item and Worktops      Phenolic Resin      Epoxy Resin      Ceramic  Stainless Steel
Raw Material  Laminated by kraft paper and phenolic resin Mixed by epoxy resin and quart Mixed by clay minerals steel
Thickness  12.7mm

15,16,19,20,25 mm

 20mm 1.0 mm
Ability to clean  OK OK OK Good
Resistance to acid-base OK OK Good Good
Resistance to corrosion resistance to corrosion of acid, alkali , solvent  resistance to corosion of acid, alkali, solvent Good resisntace to corrosion of acid, alakli and solvent  normal resistanceto corrosion of acvid , alkali, solvent
Ressitance to pollution  OK Good Good Good
Anti-Bacteria Good Good Good Good
Resistance to high temperature  OK Good Good Color changed under high temperature
Resistance to impact OK OK OK Good
Ability to bearing  Good Good Good Good
Electrical conductivity No No No Yes
Ressitance to humidity  Good Good Good Good
Resistance to Radio  Good Good

Good

 Fair
Physical Performance  solid solid solid and durable It depends






Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture 0

Lab Cabinets And Countertops Starch Resistance , Modular Laboratory Furniture 1







Tag:

steel laboratory furniture,

modular laboratory furniture,

lab systems furniture
